1.6/2.0/3.2mm Thickness High Toughness PCD Blank PCD Compact For Metal Cutting
Name: Cutting lamp
Brand: CTSTC
Original: China
The laser source is YAG, and wavelength is 1064nM. It's a little different from the traditional YAG quality, 5S Laser system is
more precision and there is no chip even enlarge 100 times at microscope. The cutting thickness is 8-10mm
Name: CNC Control
Brand: LENOVO
Original: China
Before cutting, just need to setting the data according to your drawing. It's full automatic, and you will see the cutting line
and speed online
Name: Laser cutting
Brand: CTSTC
Original: China
The repositioning accuracy is 0.002mm, and cutting table is :200*200*50mm,even a bigger diameter can be cutted. Usually the 1.6mm
thickness PCD cutting speed is 100mm/min.
Pulse Width for PCD & PCBN:
Name: After cutting PCD & PCBN
Brand: ZT-JS3S
Original: China
At 100 times enlarge microsope, you will see the part of PCD & PCBN
After cutting, there is no chip and cracks.
We are the distribute with world famous “PCD & PCBN Blanks”, below is PCD & PCBN Comparison table for reference:
● ILJIN
● ADICO
● HYPERSION
● ELEMENT 6
●TOMEI
PRODUCING STEPS
1, Our designer will make the drawing for customers confirmation as per their requirements and materials:
Cutting time: 30mins to 4hours, it’s depends on the thickness of material and the complexity of the design.
Cutting width: 0.05-0.15mm
2, Once confirmed the draw, we will using the Laser cutting machine to cut:
* The laser cutting is suitable for PCD/PCBN blank and ceramics
* Precision cutting delivery with 3 days
* Large stock for different brand material
3, QC inspection: All of the goods are finished by Laser cutting machine, our QC department will do inspection one by one, and send to our warehouse if the quality is good.
Business Scope:
Vacuum Brazing Machine
CNC/Manual Grinder for PCD/PCBN Tools
Laser Cutting/Engraving machine, Lapping machine
Distribution World Famous PCD/PCBN Blanks, Produce High Quality PCD Material
Machining Service for Laser Cutting, Polishing, Brazing, Chip Breaker of Ultra-Hard Material
Accessories for Cutting Tools Making(Oil Agglutinant, Dressing Stick, Vacuum Paste)
